Indexable Threading Toolholder: Internal & External, Left Hand, 3/4 x 3/4″ Shank
Original price was: 164,00 $.111,89 $Current price is: 111,89 $.
Specifications
| Thread Type: Internal; External | Hand of Holder: Left Hand |
| Shank Width/Diameter (Decimal Inch): 0.7500 | Shank Width/Diameter (mm): 19.05 |
| Shank Width/Diameter (Inch): 3/4 | Toolholder Style: NS |
| Insert Compatibility: N.3L | Insert Holding Method: Clamp |
| Shank Height (mm): 19.05 | Shank Height (Decimal Inch): 0.7500 |
| Shank Height (Inch): 3/4 | Overall Length (mm): 101.60 |
| Overall Length (Inch): 4 | Overall Length (Decimal Inch): 4.0000 |
| Multi-use Tool: Yes | Cutting Tool Application: Grooving; Threading |
| Head Length (Decimal Inch): 1.2500 | Head Length (mm): 31.75 |
| Maximum Depth of Cut (Decimal Inch): 0.2100 | Maximum Depth of Cut (mm): 5.33 |
| Back of Bar to Cutting Edge (Decimal Inch): 1.0000 | UNSPSC Code: 23291800 |
| Coolant Through: No | Series: Top Notch |
| Thread Type: Internal; External | |
| Hand of Holder: Left Hand | |
| Shank Width/Diameter (Decimal Inch): 0.7500 | |
| Shank Width/Diameter (mm): 19.05 | |
| Shank Width/Diameter (Inch): 3/4 | |
| Toolholder Style: NS | |
| Insert Compatibility: N.3L | |
| Insert Holding Method: Clamp | |
| Shank Height (mm): 19.05 | |
| Shank Height (Decimal Inch): 0.7500 | |
| Shank Height (Inch): 3/4 | |
| Overall Length (mm): 101.60 | |
| Overall Length (Inch): 4 | |
| Overall Length (Decimal Inch): 4.0000 | |
| Multi-use Tool: Yes | |
| Cutting Tool Application: Grooving; Threading | |
| Head Length (Decimal Inch): 1.2500 | |
| Head Length (mm): 31.75 | |
| Maximum Depth of Cut (Decimal Inch): 0.2100 | |
| Maximum Depth of Cut (mm): 5.33 | |
| Back of Bar to Cutting Edge (Decimal Inch): 1.0000 | |
| UNSPSC Code: 23291800 | |
| Coolant Through: No | |
| Series: Top Notch |
| MSC# | 88229018 |
| Mfr# | 1097261 |
| Big Book# | 915 |
