Indexable Threading Toolholder: Internal & External, Right Hand, 9.13 x 3/8″ Shank
120,99 $
Specifications
| Thread Type: Internal; External | Hand of Holder: Right Hand |
| Shank Width/Diameter (Decimal Inch): 0.3750 | Shank Width/Diameter (Inch): 3/8 |
| Toolholder Style: R166.0KF..C | Insert Compatibility: R166.0L to 11 |
| Insert Holding Method: Clamp & Screw | Shank Height (mm): 9.13 |
| Shank Height (Decimal Inch): 0.3594 | Shank Length (Inch): 6 |
| Shank Length (Decimal Inch): 6.0000 | Overall Length (Inch): 6 |
| Overall Length (Decimal Inch): 6.0000 | Minimum Bore Diameter (Decimal Inch): 0.5000 |
| Head Length (Inch): 2-1/4 | Head Length (Decimal Inch): 2.2500 |
| Maximum Depth of Cut (Decimal Inch): 2.2500 | Back of Bar to Cutting Edge (Inch): 6 |
| Back of Bar to Cutting Edge (Decimal Inch): 6.0000 | Center to Cutting Edge (mm): 7.49 |
| Center to Cutting Edge (Decimal Inch): 0.2950 | Insert Inscribed Circle (Decimal Inch): 0.2500 |
| Insert Inscribed Circle (Inch): 1/4 | Neck Diameter (Decimal Inch): 0.3750 |
| UNSPSC Code: 23291800 | Toolholder Material: Solid Carbide |
| Coolant Through: No | Series: T-Max U-Lock |
| Country of Origin: India | |
| Thread Type: Internal; External | |
| Hand of Holder: Right Hand | |
| Shank Width/Diameter (Decimal Inch): 0.3750 | |
| Shank Width/Diameter (Inch): 3/8 | |
| Toolholder Style: R166.0KF..C | |
| Insert Compatibility: R166.0L to 11 | |
| Insert Holding Method: Clamp & Screw | |
| Shank Height (mm): 9.13 | |
| Shank Height (Decimal Inch): 0.3594 | |
| Shank Length (Inch): 6 | |
| Shank Length (Decimal Inch): 6.0000 | |
| Overall Length (Inch): 6 | |
| Overall Length (Decimal Inch): 6.0000 | |
| Minimum Bore Diameter (Decimal Inch): 0.5000 | |
| Head Length (Inch): 2-1/4 | |
| Head Length (Decimal Inch): 2.2500 | |
| Maximum Depth of Cut (Decimal Inch): 2.2500 | |
| Back of Bar to Cutting Edge (Inch): 6 | |
| Back of Bar to Cutting Edge (Decimal Inch): 6.0000 | |
| Center to Cutting Edge (mm): 7.49 | |
| Center to Cutting Edge (Decimal Inch): 0.2950 | |
| Insert Inscribed Circle (Decimal Inch): 0.2500 | |
| Insert Inscribed Circle (Inch): 1/4 | |
| Neck Diameter (Decimal Inch): 0.3750 | |
| UNSPSC Code: 23291800 | |
| Toolholder Material: Solid Carbide | |
| Coolant Through: No | |
| Series: T-Max U-Lock | |
| Country of Origin: India |
| MSC# | 52078169 |
| Mfr# | 5741942 |
