Indexable Threading Toolholder: Internal, Right Hand, 15.88 x 15.88 mm Shank
120,99 $
Specifications
| Thread Type: Internal | Hand of Holder: Right Hand |
| Shank Width/Diameter (mm): 15.88 | Toolholder Style: 266.RL |
| Insert Compatibility: 266RL to 16AC01F160E; 266RL to 16AC01F140E; 266RL to 16MM01A125M; 266RL to 16AC01F120E; 266RL to 16AC01F100E; 266RL to 16MM01A300M; 266RL to 16MM01A100M; 266RL to 16MM01A200M; 266RL to 16MM01A075M; 266RL to 16MM01A250M; 266RL to 16MM01A175M; 266RL to 16MM01A150M; 266RL to 16AC01F080E; 266RL to 16MM01A050M | Insert Holding Method: Screw |
| Shank Height (mm): 15.88 | Shank Length (Decimal Inch): 6.9370 |
| Overall Length (Inch): 8 | Overall Length (Decimal Inch): 8.0000 |
| Minimum Bore Diameter (Decimal Inch): 0.7874 | Minimum Bore Diameter (mm): 20.00 |
| Multi-use Tool: Yes | Cutting Tool Application: Grooving; Threading |
| Head Length (Decimal Inch): 1.0630 | Maximum Depth of Cut (Decimal Inch): 1.8750 |
| Center to Cutting Edge (mm): 12.00 | Center to Cutting Edge (Decimal Inch): 0.4724 |
| Insert Inscribed Circle (Decimal Inch): 0.3750 | Insert Inscribed Circle (Inch): 3/8 |
| Neck Diameter (Decimal Inch): 0.6250 | Pitch Range: 64 to 8 |
| UNSPSC Code: 23291800 | Toolholder Material: Steel |
| Coolant Through: Yes | Series: CoroThread 266 |
| Country of Origin: Sweden | |
| Thread Type: Internal | |
| Hand of Holder: Right Hand | |
| Shank Width/Diameter (mm): 15.88 | |
| Toolholder Style: 266.RL | |
| Insert Compatibility: 266RL to 16AC01F160E; 266RL to 16AC01F140E; 266RL to 16MM01A125M; 266RL to 16AC01F120E; 266RL to 16AC01F100E; 266RL to 16MM01A300M; 266RL to 16MM01A100M; 266RL to 16MM01A200M; 266RL to 16MM01A075M; 266RL to 16MM01A250M; 266RL to 16MM01A175M; 266RL to 16MM01A150M; 266RL to 16AC01F080E; 266RL to 16MM01A050M | |
| Insert Holding Method: Screw | |
| Shank Height (mm): 15.88 | |
| Shank Length (Decimal Inch): 6.9370 | |
| Overall Length (Inch): 8 | |
| Overall Length (Decimal Inch): 8.0000 | |
| Minimum Bore Diameter (Decimal Inch): 0.7874 | |
| Minimum Bore Diameter (mm): 20.00 | |
| Multi-use Tool: Yes | |
| Cutting Tool Application: Grooving; Threading | |
| Head Length (Decimal Inch): 1.0630 | |
| Maximum Depth of Cut (Decimal Inch): 1.8750 | |
| Center to Cutting Edge (mm): 12.00 | |
| Center to Cutting Edge (Decimal Inch): 0.4724 | |
| Insert Inscribed Circle (Decimal Inch): 0.3750 | |
| Insert Inscribed Circle (Inch): 3/8 | |
| Neck Diameter (Decimal Inch): 0.6250 | |
| Pitch Range: 64 to 8 | |
| UNSPSC Code: 23291800 | |
| Toolholder Material: Steel | |
| Coolant Through: Yes | |
| Series: CoroThread 266 | |
| Country of Origin: Sweden |
| MSC# | 44585206 |
| Mfr# | 5961387 |
