Jobber Length Drill Bit: 3/16″ (0.1875) Dia, 118 deg, Solid Carbide
Original price was: 40,00 $.30,99 $Current price is: 30,99 $.
Specifications
| Drill Bit Size (Inch): 3/16 | Drill Bit Size (Decimal Inch): 0.1875 |
| Drill Bit Material: Solid Carbide | Drill Point Angle (Degrees): 118 |
| Coating/Finish: Bright/Uncoated | Flute Type: Regular Spiral |
| Cutting Direction: Right Hand | Point Type: Standard |
| Primary Workpiece Material: Aluminum & Non-Ferrous | Coolant Through: No |
| Number of Flutes: 2 | Flute Length (mm): 41.28 |
| Flute Length (Decimal Inch): 1.6250 | Flute Length (Inch): 1-5/8 |
| Shank Diameter (Decimal Inch): 0.1875 | Overall Length (mm): 69.85 |
| Overall Length (Inch): 2-3/4 | Spiral Type: Regular |
| Overall Length (Decimal Inch): 2.7500 | Shank Diameter (Inch): 3/16 |
| Drill Bit Diameter Tolerance: -0.0005 to 0.0000 in | Web Thinning: Web-Thinned |
| Web Configuration: Tapered | Shank Type: Straight |
| Drill Bit Grade: General Purpose | Drill Bit Size Range (Decimal Inch): 0.1500 – 0.2000 |
| Material Grade: C2 | Country of Origin: Taiwan |
| Drill Bit Size (Inch): 3/16 | |
| Drill Bit Size (Decimal Inch): 0.1875 | |
| Drill Bit Material: Solid Carbide | |
| Drill Point Angle (Degrees): 118 | |
| Coating/Finish: Bright/Uncoated | |
| Flute Type: Regular Spiral | |
| Cutting Direction: Right Hand | |
| Point Type: Standard | |
| Primary Workpiece Material: Aluminum & Non-Ferrous | |
| Coolant Through: No | |
| Number of Flutes: 2 | |
| Flute Length (mm): 41.28 | |
| Flute Length (Decimal Inch): 1.6250 | |
| Flute Length (Inch): 1-5/8 | |
| Shank Diameter (Decimal Inch): 0.1875 | |
| Overall Length (mm): 69.85 | |
| Overall Length (Inch): 2-3/4 | |
| Spiral Type: Regular | |
| Overall Length (Decimal Inch): 2.7500 | |
| Shank Diameter (Inch): 3/16 | |
| Drill Bit Diameter Tolerance: -0.0005 to 0.0000 in | |
| Web Thinning: Web-Thinned | |
| Web Configuration: Tapered | |
| Shank Type: Straight | |
| Drill Bit Grade: General Purpose | |
| Drill Bit Size Range (Decimal Inch): 0.1500 – 0.2000 | |
| Material Grade: C2 | |
| Country of Origin: Taiwan |
| MSC# | 79892329 |
| Mfr# | 79892329 |
| Big Book# | 105 |
