Milling Inserts: Insert Style: XPMT; Insert Size: 15; Insert Material: Solid Carbide; Insert Shape: Parallelogram
22,99 $
Specifications
| Insert Style: XPMT | Insert Size: 15 |
| Insert Material: Solid Carbide | Insert Shape: Parallelogram |
| Manufacturer Grade: CA6535 | Corner Radius (Decimal Inch): 0.0312 |
| Number Of Cutting Edges: 2 | Thickness (Decimal Inch – 4 Decimals): 0.1563 |
| Coating/Finish: TiCN; TiN; Al2O3 | Relief Angle: 11.000 |
| Insert Size Code: 15T308 | Width (Inch): 3/8 |
| Thickness (Inch): 5/32 | Inscribed Circle (Decimal Inch): 0.3752 |
| Inscribed Circle (Inch): 3/8 | Thickness Range (Decimal Inch): 0.1500 to 0.1750 |
| Corner Radius (Inch): 1/32 | Inscribed Circle Range (Decimal Inch): 0.3500 to 0.4000 |
| Length Range (Decimal Inch): 0.6000 to 0.6500 | Insert Hand: Neutral |
| Maximum Depth of Cut (Decimal Inch): 0.6071 | Series: OTMM |
| Coating Process: CVD | Hole Diameter (mm): 0.16 |
| Hole Diameter (Decimal Inch): 0.1575 | Rake: Positive |
| Primary Workpiece Material: Stainless Steel | Primary Workpiece Material Code: M |
| Secondary Workpiece Material: Superalloys & Titanium | Secondary Workpiece Material Code: S |
| Ansi Code: XPMT15T308CA6535 | Iso Code: XPMT15T308CA6535 |
| Standards: ISO; ANSI | Cutting Edge Style: Honed |
| Manufacturers Catalog Number: XPMT15T308 | Cutter Series Compatibility: FM-RH; EM; CM; EM-LE |
| Chip Breaker: Common | UNSPSC Code: 23291601 |
| Material Application: Stainless Steel; Superalloys & Titanium | Insert Holding Method: Screw |
| Product Service Code: 3455 | Coating Classification: CVD |
| Single or Double Sided Insert: Single | Included Angle Degree: 87 |
| Width (Decimal Inch – 4 Decimals): 0.3752 | Multi-Use Tool: Yes |
| Length (Decimal Inch – 4 Decimals): 0.6071 | Country of Origin: Japan |
| Insert Style: XPMT | |
| Insert Size: 15 | |
| Insert Material: Solid Carbide | |
| Insert Shape: Parallelogram | |
| Manufacturer Grade: CA6535 | |
| Corner Radius (Decimal Inch): 0.0312 | |
| Number Of Cutting Edges: 2 | |
| Thickness (Decimal Inch – 4 Decimals): 0.1563 | |
| Coating/Finish: TiCN; TiN; Al2O3 | |
| Relief Angle: 11.000 | |
| Insert Size Code: 15T308 | |
| Width (Inch): 3/8 | |
| Thickness (Inch): 5/32 | |
| Inscribed Circle (Decimal Inch): 0.3752 | |
| Inscribed Circle (Inch): 3/8 | |
| Thickness Range (Decimal Inch): 0.1500 to 0.1750 | |
| Corner Radius (Inch): 1/32 | |
| Inscribed Circle Range (Decimal Inch): 0.3500 to 0.4000 | |
| Length Range (Decimal Inch): 0.6000 to 0.6500 | |
| Insert Hand: Neutral | |
| Maximum Depth of Cut (Decimal Inch): 0.6071 | |
| Series: OTMM | |
| Coating Process: CVD | |
| Hole Diameter (mm): 0.16 | |
| Hole Diameter (Decimal Inch): 0.1575 | |
| Rake: Positive | |
| Primary Workpiece Material: Stainless Steel | |
| Primary Workpiece Material Code: M | |
| Secondary Workpiece Material: Superalloys & Titanium | |
| Secondary Workpiece Material Code: S | |
| Ansi Code: XPMT15T308CA6535 | |
| Iso Code: XPMT15T308CA6535 | |
| Standards: ISO; ANSI | |
| Cutting Edge Style: Honed | |
| Manufacturers Catalog Number: XPMT15T308 | |
| Cutter Series Compatibility: FM-RH; EM; CM; EM-LE | |
| Chip Breaker: Common | |
| UNSPSC Code: 23291601 | |
| Material Application: Stainless Steel; Superalloys & Titanium | |
| Insert Holding Method: Screw | |
| Product Service Code: 3455 | |
| Coating Classification: CVD | |
| Single or Double Sided Insert: Single | |
| Included Angle Degree: 87 | |
| Width (Decimal Inch – 4 Decimals): 0.3752 | |
| Multi-Use Tool: Yes | |
| Length (Decimal Inch – 4 Decimals): 0.6071 | |
| Country of Origin: Japan |
| MSC# | 30845721 |
| Mfr# | 8857926 |
