Replaceable Tip Milling Shank: Series Multimaster, 10.5 mm Projection
Original price was: 129,00 $.85,99 $Current price is: 85,99 $.
Specifications
| Shank Type: Collet | Shank Taper Size: ER16 |
| Neck Thread Size: T05 | Overall Length (Decimal Inch): 1.6970 |
| Overall Length (mm): 43.10 | Shank Shape: Conical |
| Tool Material: Solid Carbide | Neck Diameter (mm): 7.60 |
| Coolant Through: No | Toolholder Style: MM S-ER |
| Series: Multimaster | Head Length (mm): 10.50 |
| Head Length (Decimal Inch): 0.4100 | Tool Application: Milling |
| Weldon Flat: No | Effective Length (mm): 10.50 |
| Effective Length (Decimal Inch): 0.4134 | Milling Tip Style: R-8 ER; ST-ER; MM HCR; T290 ELN-MM-05; MM HBR; MM EB; MM EC-4; ST-ER-M; HP E90AN-MM-07; MM TS-N |
| Projection (mm): 10.50 | UNSPSC Code: 23291600 |
| Country of Origin: Israel | |
| Shank Type: Collet | |
| Shank Taper Size: ER16 | |
| Neck Thread Size: T05 | |
| Overall Length (Decimal Inch): 1.6970 | |
| Overall Length (mm): 43.10 | |
| Shank Shape: Conical | |
| Tool Material: Solid Carbide | |
| Neck Diameter (mm): 7.60 | |
| Coolant Through: No | |
| Toolholder Style: MM S-ER | |
| Series: Multimaster | |
| Head Length (mm): 10.50 | |
| Head Length (Decimal Inch): 0.4100 | |
| Tool Application: Milling | |
| Weldon Flat: No | |
| Effective Length (mm): 10.50 | |
| Effective Length (Decimal Inch): 0.4134 | |
| Milling Tip Style: R-8 ER; ST-ER; MM HCR; T290 ELN-MM-05; MM HBR; MM EB; MM EC-4; ST-ER-M; HP E90AN-MM-07; MM TS-N | |
| Projection (mm): 10.50 | |
| UNSPSC Code: 23291600 | |
| Country of Origin: Israel |
| MSC# | 45389806 |
| Mfr# | 3105488 |
