Sale!
Square End Mill: 1/2″ Dia, 1-1/4″ LOC
Original price was: 124,00 $.83,99 $Current price is: 83,99 $.
Specifications
| Mill Diameter (Decimal Inch): 0.5000 | Mill Diameter (Inch): 1/2 |
| Number Of Flutes: 5 | End Mill Material: Solid Carbide |
| Length of Cut (Decimal Inch): 1.2500 | Length of Cut (Inch): 1-1/4 |
| Shank Diameter (Decimal Inch): 0.5000 | Shank Diameter (Inch): 1/2 |
| Overall Length (Decimal Inch): 3.0000 | Overall Length (Inch): 3 |
| Single Or Double End: Single | Coating/Finish Family: AlTiN |
| Centercutting: Yes | Cutting Direction: Right Hand |
| Flute Direction: Right Hand | Extended Reach: No |
| Coolant Through: No | Helix Angle: 45 |
| Primary Workpiece Material: Aluminum & Non-Ferrous; High-Temp Alloy; Stainless Steel; Cast Iron; Steel; Hardened Materials | Primary Workpiece Material Code: P; S; H; K; M; N |
| Coating/Finish: AlTiN | Variable Helix: No |
| Variable Index: No | Chipbreaker: No |
| Flute Type: Spiral | Shank Type: Straight-Cylindrical |
| Material Grade: Micrograin | Length Of Cut Range (Decimal Inch): 1.2500 – 1.5000 |
| Mill Diameter Tolerance: -0.0000/-0.0020 in | Shank Diameter Tolerance: -0.0001/-0.0004 in |
| Overall Length Tolerance: +0.0015/-0.0015 in | TIR Maximum (Decimal Inch): 0.0005 |
| Series: S545 | System Of Measurement: Fractional Inch |
| UNSPSC Code: 27112803 | Country of Origin: UNITED STATES |
| Mill Diameter (Decimal Inch): 0.5000 | |
| Mill Diameter (Inch): 1/2 | |
| Number Of Flutes: 5 | |
| End Mill Material: Solid Carbide | |
| Length of Cut (Decimal Inch): 1.2500 | |
| Length of Cut (Inch): 1-1/4 | |
| Shank Diameter (Decimal Inch): 0.5000 | |
| Shank Diameter (Inch): 1/2 | |
| Overall Length (Decimal Inch): 3.0000 | |
| Overall Length (Inch): 3 | |
| Single Or Double End: Single | |
| Coating/Finish Family: AlTiN | |
| Centercutting: Yes | |
| Cutting Direction: Right Hand | |
| Flute Direction: Right Hand | |
| Extended Reach: No | |
| Coolant Through: No | |
| Helix Angle: 45 | |
| Primary Workpiece Material: Aluminum & Non-Ferrous; High-Temp Alloy; Stainless Steel; Cast Iron; Steel; Hardened Materials | |
| Primary Workpiece Material Code: P; S; H; K; M; N | |
| Coating/Finish: AlTiN | |
| Variable Helix: No | |
| Variable Index: No | |
| Chipbreaker: No | |
| Flute Type: Spiral | |
| Shank Type: Straight-Cylindrical | |
| Material Grade: Micrograin | |
| Length Of Cut Range (Decimal Inch): 1.2500 – 1.5000 | |
| Mill Diameter Tolerance: -0.0000/-0.0020 in | |
| Shank Diameter Tolerance: -0.0001/-0.0004 in | |
| Overall Length Tolerance: +0.0015/-0.0015 in | |
| TIR Maximum (Decimal Inch): 0.0005 | |
| Series: S545 | |
| System Of Measurement: Fractional Inch | |
| UNSPSC Code: 27112803 | |
| Country of Origin: UNITED STATES |
| MSC# | 63738116 |
| Mfr# | 17003612 |
| Big Book# | 515 |
